SPECIFICATIONS

Brand Name: ZIYOUHU

Origin: Mainland China

Model Number: F5

Detector Type: Uncooled focal plane micro-heat type

Resolution Ratio: 384*288

Frame Frequency (Refresh Rate): 50/60HZ

Angle of View Field: 49.2°X36.3°

Display: 4.3" TFT color LCD display, resolution 800*480

Color Mark Mode: Black hot, white hot, fire protection, iron red, firefighting, search & rescue

Image Spatial Resolution: 2.58mrad

Temperature Measurement Range: From -20°C to +1200°C, automatic shift

Temperature Measurement Accuracy: ±10°C or ±10% of the measured value, which is greater

Other Configuration: Compass,Laser Ranging,WiFi,Data Interface
